DressMapper / Vista — assisted pattern-grading rule transfer
A prototype matching DXF sewing patterns against reference models and transferring grading rules through a reviewable web workflow.
- Commissioned by
- Magenta SRL
- End client
- VISTA SRLS
The project at a glance · Illustrated overview
From patterns to matching pieces.
Upload
Reading DXF garment patterns.
Comparison
Matching geometry with reference patterns.
Review
The operator checks the associations.
Grading
Transferring rules and exporting DXF/RUL files.
01
The challenge
Reusing grading rules on new patterns requires matching pieces and geometry and checking the proposed correspondences.
02
The solution
A Python engine extracts geometry and ranks reference matches. A Laravel interface supports uploads, reference selection, mapping review and DXF/RUL generation through the engine API.
03
Capabilities
- DXF pattern loading and previews.
- Reference-library matching.
- Geometric and semantic component matching.
- Web-based mapping review.
- Grading-rule transfer and DXF/RUL output.
- Flask API connecting Python and Laravel.
